[3-day course, Euro 3,450.- (net) per participant]

backtotop.gifA Comprehensive Inside View on GPRS

Course Description

  • Overall Network Architecture with Release 5
    • Overview
  • The GPRS Access and Core Network Architecture
    • The All-IP Backbone Configuration with Release 5
    • GPRS-Mobility Management
    • GPRS-Session Management
    • Ciphering
    • Charging (own network resources)
    • Data Compression (<-> V.42bis)
    • TCP/IP Header Compression (<-> RFC 1144)
    • TCP/IP und UDP Header Compression (<-> RFC 2507)
  • Tasks and Functions of the GGSN
    • Interface between the PLMN and external Packet Data Networks
    • Anchor Function for Packet Data Transfer
    • Charging (foreign network resources)
  • There are Different Types of GGSN’s
    • GGSN Type A (Transparent Access)
    • GGSN Type B (Non-Transparent Access)
    • GGSN Type C (Corporate GGSN)
  • Tasks and Functions of the BG
    • Interface for Packet Data Transmission between PLMN’s
  • The Network Operation Mode with GPRS
    • Network Operation Mode I (NOM I)
    • Network Operation Mode II (NOM II)
    • Network Operation Mode III (NOM III)
  • The Network Operation Mode with UMTS
  • The Network Operation Mode with UMTS
    • Network Operation Mode I (NOM I)
    • Network Operation Mode II (NOM II)
  • The GPRS Protocol Stack between MS and Application
    • The Protocol Stack only presents the packet-switched view
    • GPRS is only a Bearer
  • Protocols within the GPRS Access Network
    • BSSGP and Network Service
    • LLC and SNDCP
    • Functions of RLC/MAC
  • The UMTS Protocol Stack between MS and Application
    • Packet-Switched Control Plane
      - Access Stratum Protocols
      - Non Access Stratum Protocols
    • Packet-Switched User Plane
  • Iu mode
    • GERAN – Core Network Interfaces with Release 5
    • IMS introduction in the Core Network
  • GERAN in Iu mode connected to PS Domain
    • User Plane
    • Control Plane
    • New Identifier in Iu mode
    • S-RNTI
    • G-RNTI
  • Intra GERAN, inter GERAN – UTRAN interface
    • General principles of the Iur-g interface
    • GERAN Registration Area
  • Flexible Iu Connection
    • Load Distribution
    • Reduced Signaling
    • Capacity Upgrade
    • Node Redundancy
    • Flexible Iu Interface with Release 5
    • Packet Switched Pool Areas
    • Circuit Switched Pool Areas
      - NRI transmission in A/Gb mode
      - NRI transmission in Iu mode
    • Affected Network Nodes
      - Network Configuration Example

backtotop.gifGPRS Mobility Management (GMM) and GERAN / UTRAN Interworking

  • Introduction to GPRS Mobility Management
    • Intra-PLMN and Inter-PLMN Roaming
    • GMM States in the SGSN and the Mobile Station (GPRS)
      - The IDLE-State
      - The READY-State
      - The STANDBY-State
    • PMM States in the SGSN and the Mobile Station (UMTS)
      - PMM-Detached-State
      - PMM-Connected-State
      - PMM-Idle-State
    • The Routing Area and the Null Routing Area
      - The Routing Area Identification (RAI)
      - The Routing Area Identification (RAI)
  • Other Important GMM-Identifiers
    • The P-TMSI and the P-TMSI Signature
    • The Ready Timer (T3314) (GPRS only)
    • The Ready Timer (T3314) (GPRS only)
      - Operation of the Ready Timer (T3314)
      - Operation of the Ready Timer (T3314)
      - Implications of the Ready Timer:
      - Reduction of the Paging Time
    • Periodic Routing Area Updating Timer (T3312) & Mobile Reachable Timer
      - Expiry of T3312 in MS
      - Allocation of T3312 and Mobile Reachable Timer
      - Operation of T3312 and Mobile Reachable Timer
      - Expiry of Mobile Reachable Timer
  • The GMM-Messages
    • Message Format for GMM
    • The GMM Message Types
      - ATT_REQ
      - ATT_ACC
      - ATT_COM
      - ATT_REJ
      - DET_REQ
      - DET_ACC
      - RA_UPD_REQ
      - RA_UPD_ACC
      - RA_UPD_COM
      - RA_UPD_REJ
      - P-TMSI_REAL_CMD
      - P-TMSI_REAL_COM
      - AUTH_CIPH_REQ
      - AUTH_CIPH_RSP
      - AUTH_CIPH_REJ
      - IDENT_REQ
      - IDENT_RSP
      - GMM_STATUS
      - GMM_INFO
  • GMM-Procedures
    • GPRS Attach ( new SGSN / NOM II / III, MS Class A, B or C)
      - Initial Conditions
      - Applicability of this Procedure
      - Description
    • Combined Attach (no new SGSN, MS Class A or B)
      - Initial Conditions
      - Applicability of this Procedure
      - Description
    • Combined RA / LA Update (Intra SGSN / MS-Class A or B)
      - Initial Conditions
      - Applicability of this Procedure
      - Description
    • Inter SGSN Routing Area Update (GPRS in A/Gb-mode)
      - Initial Conditions
      - Applicability of this Procedure
      - Description
    • Inter SGSN Routing Area Update (UMTS / MS-initiated)
      - Initial Conditions
      - Applicability of this Procedure
      - Description
    • The GPRS Detach Procedure (Mobile Originating)
      - Initial Conditions
      - Applicability of this Procedure
      - Description
    • The GPRS Detach Procedure (SGSN Originating)
      - Initial Conditions
      - Applicability of this Procedure
      - Description
    • The GPRS Detach Procedure (HSS Originating)
      - Initial Conditions
      - Applicability of this Procedure
      - Description
  • Interworking between UTRAN and GERAN
    • Overview
    • State Transitions GMM <-> PMM
      - Case 2: From GERAN to UTRA
  • Related Scenarios (Selection)
    • MS Initiated Inter-SGSN RA Update UMTS -> GPRS
      - Initial Conditions
      - Applicability of this Procedure
      - Description
    • SRNS-Relocation with RA-Update GPRS to UMTS (Iu-mode)
      - Initial Conditions
      - Applicability of this Procedure
      - Description

backtotop.gifThe IP Backbone

  • Introducing the IP-Protocol Stack
    • The Structure of the IP-Protocol Stack
  • Details of the Internet Protocol
    • IP-Addresses
      - IP-Address Classes
      - Special IP-Address Notations
      - Subnet-Addressing
      - Supernetting and CIDR
      - More Details of Classless Inter-Domain Routing
    • The IP-Header
      - Overview
      - Example of an IP-Header
      - The IP-Header / Octet 1 – 4
      - The TOS- Field (Type of Service)
      - The TOS- Field / Differentiated Services
      - The IP-Header / Octet 5 – 8
      - Fragmentation Control in IP
      - The IP-Header / Octet 9 – 20
      - The IP-Header / Octet 21 – N (IP-Options)
  • Details of the Internet Control Message Protocol (ICMP)
    • ICMP-Message Format
    • ICMP-Messages
      - Echo Reply
      - Destination Unreachable
      - Source Quench
      - Redirect
      - Echo Request
      - Router Advertisement
      - Router Solicitation
      - Time Exceeded for a Datagram
      - Parameter Problem on a Datagram
      - Timestamp Request
      - Timestamp Reply
      - Information Request
      - Information Reply
      - Address Mask Request
      - Address Mask Reply
    • Example of an ICMP-Message (Router Solicitation)
  • Details of the User Datagram Protocol (UDP)
    • Services of UDP
      - Application Process Identification
      - Connection-less / Unacknowledged Data Delivery
      - Frame Protection (Checksum)
    • Port Numbers
      - “Well known” Port Numbers
      - Available Port Numbers
    • The UDP-Header
      - Source Port (16 bit) / Destination Port (16 bit)
      - Length (16 bit)
      - Checksum (16 bit)
      - UDP-Pseudo Header and UDP-Checksum
  • Details of the Transmission Control Protocol (TCP)
    • Services of TCP
    • TCP Connection Establishment
      - Example for TCP Connection Establishment
    • TCP Connection Release
      - Example for TCP Connection Release
    • The TCP-Header
      - The TCP-Header / Octet 1 – 12
      - The TCP-Header / Octet 13 – 20
      - The TCP-Header / Octet 21 – n (Options)
    • Sliding Windows in TCP
  • The Process of IP-Address Allocation
    • The Dynamic Host Configuration Protocol (DHCP)
      - Automatic Allocation
      - Dynamic Allocation
      - Manual Allocation
    • Operation of an initial DHCP Request
    • Operation of an initial DHCP Request
    • Operation of the DHCP in GPRS and UMTS
  • Private IP-Addresses
    • Mobile Subscribers entering the Internet
    • Private IP-Address Ranges
    • Using Network Address Translation (NAT) for Interconnection
    • Principles of Network Address Translation
    • Liabilities of NAT
      - IPsec in Transport Mode
      - Streaming Applications
      - Push Services
  • Access to Applications -> The Domain Name System (DNS)
    • Structure of the Domain Name System (DNS)
    • Structure of the Domain Name System (DNS)
    • Operation of DNS
    • Operation of DNS
  • Details of the Stream Control Transmission Protocol (SCTP)
    • The SCTP Header
    • The SCTP Header
    • The SCTP Chunks / Octet 13 - 16
    • The SCTP Chunks / Octet 13 - 16
    • SCTP Chunk Types
    • SCTP Association Establishment
    • SCTP Association Establishment
  • SIGTRAN
    • SCTP in the Signaling Gateway Function (SIGTRAN)
    • Transport Protocol Comparison
  • The Need for QoS in IP Networks
  • QoS Options in IP-Networks
    • Operation of Integrated Services
    • Operation of Differentiated Services
      - Per-Hop forwarding Behavior (PHB)
    • DiffServ <-> IntServ
    • Operation of MPLS
      - Routing Labels
  • Speed Proxies and their Operation

backtotop.gifThe GPRS Tunneling Protocol (GTP / GTP’)

  • The Protocol Stack in the Core Network
    • Interconnecting the GGSN to External Packet Data Networks
  • Applicability of GTP-C, GTP-U and GTP’
    • GTP-C
    • GTP-U
    • GTP’
  • Definition of T-PDU, G-PDU and N-PDU
    • N-PDU
    • G-PDU
    • T-PDU
  • Definition of GTP Paths and Tunnels
    • GTP-Path
    • GTP-Tunnel
    • Allocation of the TEID during PDP-Context Establishment
    • GTP-Tunnel Establishment Procedure between two SGSNs
  • Functions of GTP
    • Path Management
    • Tunnel Management
    • Location Management
    • Mobility Management
    • GTP Procedures / Timer and Counter
      - T3-Response Timer / N3-Request Counter
      - T3-Tunnel Timer
      - N3-Buffer Size
  • GTP-Messages
    • GTP-C PDU Format
      - Version
      - PT (Protocol Type)
      - E-flag (Extension header-flag)
      - S-flag (Sequence number flag)
      - PN-flag (N-PDU number flag)
      - Message Type
      - Length
      - TEID (Tunnel Endpoint Identifier)
      - Sequence Number
      - N-PDU No
    • Example of a GTP-C PDU
    • GTP-U PDU Format
    • GTP-U PDU Format
      - Version
      - PT (Protocol Type)
      - E-flag (Extension header-flag)
      - S-flag (Sequence number flag)
      - PN-flag (N-PDU number flag)
      - Message Type
      - Length
      - TEID (Tunnel Endpoint Identifier)
      - Sequence Number
      - N-PDU No
    • Example of a GTP-U PDU
    • Information Element Encoding in GTP-C, GTP-U and GTP’
      - Type-Value (TV) Encoding and Type-Length-Value (TLV) Encoding
    • The GTP’-Message Format
      - Version
      - PT (Protocol Type)
      - Message Type
      - Length
      - Sequence Number
    • The GTP/GTP’-Message Types
      - ECHO_REQ
      - ECHO_RSP
      - VERS_NOT_SUPP
      - NODE_ALIVE_REQ
      - NODE_ALIVE_RSP
      - REDIR_REQ
      - REDIR_RSP
      - CT_PDP_CT_REQ
      - CT_PDP_CT_RSP
      - UPD_PDP_CT_REQ
      - UPD_PDP_CT_RSP
      - DEL_PDP_CT_REQ
      - DEL_PDP_CT_RSP
      - ERR_IND
      - PDU_NOT_REQ
      - PDU_NOT_RSP
      - PDU_NOT_REJ_REQ
      - PDU_NOT_REJ_RSP
      - SEND_ROUT_INFO_GPRS_REQ
      - SEND_ROUT_INFO_GPRS_RSP
      - FAIL_REP_REQ
      - FAIL_REP_RSP
      - NOT_MS_GPRS_PRES_REQ
      - NOT_MS_GPRS_PRES_RSP
      - IDENT_REQ
      - IDENT_RSP
      - SGSN_CT_REQ
      - SGSN_CT_RSP
      - SGSN_CT_ACK
      - FW_RELOC_REQ
      - FW_RELOC_RSP
      - FW_RELOC_COM
      - RELOC_CANCEL_REQ
      - RELOC_CANCEL_RSP
      - FW_SRNS_CT
      - FW_RELOC_COM_ACK
      - FW_SRNS_CT_ACK
      - RAN_INFO_RELAY
      - DATA_REC_TRANS_REQ
      - DATA_REC_TRANS_RSP
    • Example of an ECHO RSP-Message
  • Types of Charging Data Records (CDR)
    • S-CDR
    • M-CDR
    • G-CDR
      - S-SMO-CDR / S-SMT-CDR
    • LCS-MO-CDR
    • LCS-MT-CDR
    • LCS-NI-CDR
  • Exchange of CDR’s
    • Initial Conditions
    • Applicability of this Procedure
    • Description

backtotop.gifSession Management (SM) in GPRS

  • Parameters of Session Management
    • The QoS-Parameters in Release ’99 and beyond
    • Applicability of the QoS-Profile
    • Applicability of the QoS-Profile
    • The Traffic Classes
      - Conversational Class:
      - Streaming Class:
      - Interactive class:
      - Background class:
      - Relationship between QoS-Profile and Application
      - The File Transfer Protocol (FTP)
      - Voice over IP (VoIP)
      - The Packet Flow Context (PFC) and the Packet Flow Identifier (PFI)
    • The Different PDP-Types
    • The Access Point Name (APN)
      - The Network Identifier
      - The Operator Identifier
      - Example: Network Selection with APN = “*” and PDP-Type = IP
      - Example: Network Selection with APN = “WAP” and PDP-Type = IP
      - Example: Network Selection without provision of APN or PDP-Type
      - Example: Network Selection with APN = “UUDIAL.NET” (or without provision of APN) and
        PDP-Type = PPP
    • Protocol Configuration Options
    • PDP-Context Parameter Storage
    • Message Format for SM
    • Message Format for SM
    • The SM-Message Types
      - ACT_PDP_CT_REQ
      - ACT_PDP_CT_ACC
      - ACT_PDP_CT_REJ
      - REQ_PDP_CT_ACT
      - REQ_PDP_CT_ACT_REJ
      - DEACT_PDP_CT_REQ
      - DEACT_PDP_CT_ACC
      - MOD_PDP_CT_REQ (SGSN => MS)
      - MOD_PDP_CT_ACC (MS => SGSN)
      - MOD_PDP_CT_REQ (MS => SGSN)
      - MOD_PDP_CT_ACC (SGSN => MS)
      - MOD_PDP_CT_REJ
      - ACT_SEC_PDP_CT_REQ
      - ACT_SEC_PDP_CT_ACC
      - ACT_SEC_PDP_CT_REJ
      - SM_STATUS
  • Transparent Access to the Internet / Intranet
    • Network Configuration after Transparent Access
  • Non-Transparent Access to the Internet / Intranet
    • Network Configuration after Non-Transparent Access
  • Session Management Procedures
    • The Operation of Session Management Procedures
    • The Mobile Originating PDP-Context Activation Procedure
      - Initial Conditions
      - Applicability of this Procedure
      - Description
    • The Mobile Terminating PDP-Context Activation Procedure
      - Initial Conditions
      - Applicability of this Procedure
      - Description
    • PDP-Context Deactivation – Mobile Originating
      - Initial Conditions
      - Applicability of this Procedure
      - Description
    • PDP-Context Deactivation – SGSN Originating
      - Initial Conditions
      - Applicability of this Procedure
      - Description
    • PDP-Context Deactivation – GGSN Originating
      - Initial Conditions
      - Applicability of this Procedure
      - Description

backtotop.gifVirtual Private Networking with GPRS (VPN & IPsec)

  • Security Concerns for Internet Traffic
    • Privacy
    • Alteration
    • Spoofing
  • Security Analysis of Typical Network Configurations
    • Subnet <- SECURE BACKBONE -> Central Corporate
    • Subnet <- LEASED LINE -> Central Corporate
    • “Road Warrior” <- DIAL UP / INTERNET -> Central Corporate
    • Other Corporate Networks <- INTERNET -> Central Corporate
  • Alternatives for Network Security
    • Encryption and Authentication on Layer 1 / 2
    • Encryption and Authentication on the Network Layer
    • Encryption and Authentication on higher layers
  • VPN Operation Modes
    • IPsec in Transport Mode
      - Transport Mode and AH
      - Transport Mode and ESP
    • IPsec in Tunnel Mode
      - Tunnel Mode and AH
      - Tunnel Mode and ESP
    • VPN with IPsec in Tunnel Mode and Transport Mode
      - VPN with IPsec in Tunnel Mode
      - VPN with IPsec in Transport Mode
  • The IPsec Authentication Header (AH)
    • Next Header (8 bit)
    • Payload Length (8 bit)
    • Reserved (16 bit)
    • Security Parameters Index (SPI) (32 bit)
    • Sequence Number (32 bit)
    • Authentication Data (n bit)
  • The IPsec Encapsulating Security Payload (ESP)
    • Security Parameters Index (SPI) (32 bit)
    • Sequence Number (32 bit)
    • Payload Data (n bit)
    • Padding (0 – 255 octets)
    • Padding Length (8 bit)
    • Next Header (8 bit)
    • ESP Authentication Data (n bit)
  • The Security Association (SA)
  • Algorithms for IPsec
    • How does a Hash Algorithm Work?
      How does Encryption Work with IPsec?
  • Establishment of an IPsec-Relationship
    • ISAKMP (Internet Security Association and Key Management Protocol)
      - Authentication through Signatures
      - Authentication through Pre-Shared Key
      - Authentication through Public Key Encryption

v5.2
